About GSUIT
GSUIT is one of the excellent products as PPF from Ad-winner for car paint protection. This is the most effective way to protect vehicles from environmental, physical and chemical damages.
The actual meaning of GSUIT is a safe gear that pilots wear to protect themselves in flight. Implying the characteristic of the pilot safe suit, our product, GSUIT, keeps vehicles intact from any external substance.
GSUIT is an Anti-chipping film made of thermoplastic polyurethane. It is not only used as an interior design element, but also exterior decoration. The painted surface of various vehicles including cars, bicycles, motorcycles, boats, airplanes etc. can be wrapped with our GSUIT to get protection.
- The Film thickness reaches 200 micron, which ensures protection from mechanical and chemical influences.
- GSUIT has excellent transmittance and gloss, which makes the color of paint darker.
- GSUIT defends against physical and chemical contamination with its excellent water repellency.
- The flawless adhesive layer does not peel off easily and can be easily peeled off during use.
- The excellent crosslinking performance of the film keeps the car’s painted surface much longer clean and non-yellowing.
Products Feature
| Test Item | Special | Ultra | Aegis | Prime | Matt | Test Condition |
|---|---|---|---|---|---|---|
| Appearance | Clear | Clear | Clear | Clear | Clear | |
| Top coating | ○ | ○ | ○ | ○ | ○ | |
| Gloss(%) | >98% | >96% | >96% | >96% | <20% | 60˚ |
| Transparency(%) | >95% | >95% | >96% | >96% | >90% | Haze meter |
| Hydrophobic(˚) | >95 | >95 | >96 | >96 | >90 | Angle contact |
| Self-healing(℃) | >120 | >120 | >180 | >25 | >60 | Heat gun |
| Anti-premeation | ★★★★ | ★★★★ | ★★★★★ | ★★★ | ★★★ | Permanent marker |
| Anti-yellowing(△E) | <0.8 | <0.8 | <0.6 | <0.6 | <0.6 | Q-UV 1,000hrs |
| Stain resistance | ★★★★ | ★★★★★ | ★★★★★ | ★★★★ | ★★★★ | Motor waste oil |
| Anti-chipping | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | SAE J400 |
| 100% Modulus(kg/㎠) | <90 | <100 | <200 | <100 | <100 | ASTM D412 |
| Tensile strength(kg/㎠) | >300 | >190 | >300 | >250 | >200 | ASTM D412 |
| Elongation(%) | >500 | >300 | >300 | >250 | >300 | ASTM D412 |
| Peel adhesion(g/in.) | >1,400 | >1,400 | >1,400 | >1,200 | >1,200 | ASTM D3654 |
| Thickness(㎛) | 184±2 | 185±2 | 185±2 | 200±2 | 190±2 |
(Scroll sideways to see more.)
| Test Item | Black High Glossy | Black Matt | Head Light | Black Carbon | Test Condition | |||
|---|---|---|---|---|---|---|---|---|
| Soft Black | Dark Black | Gray | Violet | |||||
| Top coating | ○ | ○ | ○ | ○ | ○ | ○ | ○ | |
| Gloss(%) | >96% | <20% | >96% | >96% | >96% | >96% | 60˚ | >96% |
| Transparency(%) | >80% | >40% | >70% | >60% | Haze meter | |||
| Hydrophobic(˚) | >95 | >90 | >95 | >95 | >95 | >95 | Angle contact | >95 |
| Self-healing(℃) | >100 | >60 | >100 | >100 | >100 | >100 | Heat gun | >100 |
| Anti-premeation | ★★★★ | ★★★★ | ★★★★ | ★★★★ | Permanent marker | |||
| Anti-yellowing(△E) | <0.1 | <0.1 | <0.8 | <0.8 | <0.8 | <0.8 | Q-UV 1,000hrs | <0.1 |
| Stain resistance | ★★★★★ | ★★★★★ | ★★★★ | ★★★★ | ★★★★ | ★★★★ | Motor waste oil | ★★★★★ |
| Anti-chipping | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | ★★★★★ | SAE J400 | ★★★★★ |
| 100% Modulus(kg/㎠) | <170 | <100 | <90 | <90 | <90 | <90 | ASTM D412 | <150 |
| Tensile strength(kg/㎠) | >300 | >200 | >300 | >300 | >300 | >300 | ASTM D412 | >300 |
| Elongation(%) | >400 | >300 | >500 | >500 | >500 | >500 | ASTM D412 | >350 |
| Peel adhesion(g/in.) | >1,400 | >1,200 | >1,400 | >1,400 | >1,400 | >1,400 | ASTM D3654 | >1,400 |
| Thickness(㎛) | 150±2 | 150±2 | 184±2 | 184±2 | 184±2 | 184±2 | 280±5 | |
